12.5″ 320mm A Pair Rear Shocks Absorber Replace Some Honda CX 500 CX 650 Rear Suspension

Categories
Product tags
air filter axle Baja Mini Bike MB165 & MB200 Bearings belt bolt bracket brake brake cable brake link bushing bushing block carburetor centrifugal clutch chain chain buckle clutch clutch cable clutch parts connecting link drive belt exhaust muffler pipe exhaust muffler tube exhaust pipe front fork gasket handle ignition coil latch liner bushing lining roller chain shaft shock absorber sleeve bushing split link spring sprocket starter motor throttle cable tire Tires Rims Wheels tool tyre washer
12.5" 320mm A Pair Rear Shocks Absorber Replace Some Honda CX 500 CX 650 Rear Suspension
12.5" 320mm A Pair Rear Shocks Absorber Replace Some Honda CX 500 CX 650 Rear Suspension - Image 2
12.5" 320mm A Pair Rear Shocks Absorber Replace Some Honda CX 500 CX 650 Rear Suspension - Image 3
12.5" 320mm A Pair Rear Shocks Absorber Replace Some Honda CX 500 CX 650 Rear Suspension - Image 4

12.5″ 320mm A Pair Rear Shocks Absorber Replace Some Honda CX 500 CX 650 Rear Suspension

SKU JZQ.04396 Category Tags ,

SPREAD THE LOVE

Description

A Pair of Round Hole 320mm Aluminum and Solid Steel Shock Absorber

Pressure can be adjusted by springs or air (nitrogen); Operation of the coil-over springs and air cylinder is helpful to reduce the shock.

Shock Absorber bottom/ends type: Round End

No instruction included, professional installation recommended.

Universal fit for most 320mm Motorcycle Shock Absorber For Honda/Yamaha/Suzuki/Kawasaki;Dirt bikes, Gokart, ATV, Motorcycles and Quad. Please check your mounting measurement before purchase.
Description:
Dimension:
Total Length: 350mm (13 3/4″)
Length of Eye to Eye Core: 320mm (12 5/8″)
Eye Diameter(with bushing): 12mm
Eye Diameter(with bushing removed): 16mm
Eye Thickness: 21mm
Eye Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 7mm
Spring Width: 60mm
WorStroke: 60mm
Spring Stiffness: 110 kg
Maximum load/Pair: 200 kg (440 lbs)
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
A complete pair RFY air ga
