12.5″ 320mm Motorcycle Shock Absorbers Clevis End Universal Fit 125cc-200cc Honda Suzuki Yamaha Kawasaki ATV Go Kart Quad Dirt Sport Bikes
SPREAD THE LOVE
Description
A Pair of U-Shape 320mm Aluminum and Solid Steel Shock Absorber
Pressure can be adjusted by springs or air (nitrogen); Operation of the coil-over springs and air cylinder is helpful to reduce the shock.
Shock Absorber bottom/ends type: U-Type( Clevis End )
No instruction included, professional installation recommended.
Universal fit for most 320mm Motorcycle Shock Absorber For Honda/Yamaha/Suzuki/Kawasaki;Dirt bikes, Gokart, ATV, Motorcycles and Quad.
Color:Black and Gold, U Shape
Description:
Dimension:
Total Length: 350mm (13 3/4″)
Length of Eye to Clevis Eye Core: 320mm (12 5/8″)
Clevis Hole Diameter: 8mm
Clevis Inner Width: 20mm
Clevis Maximum Tensile Strength: 2,000 Kgf
Spring Thickness: 7mm
Spring Width: 60mm
WorStroke: 60mm
Spring Stiffness: 110 kg
Maximum load: 200 kg (440 lbs)
Air Reservoir: Adjustable
Factory Air Pressure: 0.4 Mpa
Maximum Air Pressure: 0.5 Mpa
A complete pair RFY air gas shocks absorbers
Easy to install,no Installation Instr
