Chain – Purchase by the Foot #35, #415, #40, #41, #420, #520, #530 Pitch Chain
SPREAD THE LOVE
Description
Choice of #35, #415, #40, #41, #420, #520, #530 Pitch Chain
Pricing is per foot, so please enter the number of feet you want in the quantity box.
Standard Roller Chain Specifications & Strengths
Chain SizePitchRoller Dia.Roller WidthPin Dia.Ave. Tensile#2197.774mm (~5/16″)
4.59mm5.00mm
3.01mm
2NA#353/8″.200″3/16″.141″2,100#4151/2″.312″3/16″.141″NA
#411/2″.306″1/4″.141″2,000#4201/2″.306″1/4″.156″3,700#4281/2″.312″1/4″.187″NA#401/2″.312″5/16″.156″3,700#5205/8″
.400″
1/4″
13/64″
6,100#5305/8″
.400″
3/8″
13/64″
6,100
Many chains have the chain size stamped directly on the chain links #35,40,41 & 420 chain are used in the Fun Kart and Mini Bike Industry.
An 11 or 12 tooth clutch sprocket usually indicates the use of #35 chain
10 tooth clutch sprockets usually indicate the use of #40, 41 or 420 chain
Make sure you order enough chain, any extra links can always be removed
#415 chain is also known as 1/2″ x 3/16″ and 083 chain. It is suited for all types of motorized bikes, freight bicy
