Product Description
Billet Aluminum engine mounting plate for DoodleBug DB30 and MotoVox minibikes. This is also great for custom engine installations!
Drilling 4 holes may be required!
This is the plate to allow you to swap your 79cc/97cc engine to a larger engine, such as a Honda clone, Predator 212cc, Tecumseh, Briggs, Subaru, etc. Includes hardware for installation.
Basic Installation Instructions
– Remove the engine from the mini bike frame
– Remove the spacer the old engine was sitting on
– Use the plate as a template to drill (4) 5/16″ holes
– Bolt the adapter plate to the frame
– Put the engine on the adapter plate
– Now you have front to back and side to side adjustability for your motor
Approximate measurements:
Length – 6″
Width – 7-1/2″
Thickness – 7/16″
