Genuine Mikuni VM22 Carburetor, for Honda GX120/160/200, Titan, Predator 212 and clones

Genuine Mikuni VM22 Carburetor, for Honda GX120/160/200, Titan, Predator 212 and clones
The cheap chinese ‘mikuni’ 22 carburetor does not work well out of the box unless you re-jet it. We sell those also, but we recommend genuine.
This 22mm Genuine Mikuni carburetor works great on Honda GX160/200 and most 70-125cc Pit Bike engines. adds about 2-3hp and increased torque over stock carb and is fuel mixture adjustable. The 22mm is the right choice if you are running stock valves
Mikuni CARBURETOR
This 22mm Mikuni carburetor works great on Titan and Honda GX160/200 and most 70-110-125cc Pit Bike engines. adds about 1-2hp and increased torque over stock carb and is fuel mixture adjustable. The 22mm is the right choice if you are running stock valves
engine will come alive in both top end and low end torque and acceleration as well as a very responsive throttle.
Download the Mikuni Carb INSTALLATION INSTRUCTIONS
Download the HPO High Performance Option Installation Guide
Mikuni MAIN JETS
22mm Mikuni carburetor (gasoline) works great on Honda GX160/200 and clone engines. It adds about 1-2hp and increased torque over the stock Honda carburetor and is fuel mixture adjustable for optimum performance and tuning. The 22mm is the right choice if you are running stock valves.
Use our Mikuni Intake Manifold adapter, sold separately, to mount this carb on a Honda GX160/200 or clone including Titan and Predator. The Manifold also angles the air filter back towards the engine in optimum position for a minibike.
Standard Jetting Specifications
Carburetor
Venturi Size
Main jet (VM4/042)
Pilot Jet (VM22/210)
Needle Jet
Jet Needle
Throttle Valve
Air Jet
Needle Valve
VM22-133
22
100
30
N-8
4D20
2.0
2.5
2.0
Mikuni’s VM Series round slide single carburetors have proven themselves as the performance standard for use in any single cylinder motorcycle and ATV application for motocross, enduro and trail riding, to flat track racing and road racing on both 2-stroke and 4-stroke engines.
Performance features for the VM series carburetors include a large selection of bore sizes for fuel mixture flow to match any engine modifications. A wide range of tuning components to allow precise fuel mixture metering in any application, at any throttle setting, and under any riding condition.
SKU
VM22-133
Manufacture
Mikuni
Carburetor Application
General
Carburetor Size
22mm
Carburetor Type
Round Slide
Carburetor Mount
Bolt On Flange
Intake Bell Diameter
43mm
Engine Side Diameter
49mm Spacing
Idle Location
Left
Accelerator Pump
No
Carburetor Depth
85mm
Carburetor Height
114mm
Carburetor Width
82mm
Slide Type
VM26/21
Main Jet Series
VM4/042
Pilot Jet Series
VM22/210
Needle Jet Series
257
Needle Series
#4
Needle & Seat Type
VM26/26
Starter Jet Series
VM17/1002
Air Jet Series
BS30/97
Float Height
24mm-26mm
cannot be sold in California, closed course competition only
