Go Kart/Mini Bike Clutch Centrifugal Clutch Engine Clutch 5/8 Inch Bore #35 Chain 12 Tooth 12T Chain 6.5HP

Go Kart/Mini Bike Clutch Centrifugal Clutch Engine Clutch 5/8 Inch Bore #35 Chain 12 Tooth 12T Chain 6.5HP

SKU LHQ.07532 FA0010 Category Tags ,

SPREAD THE LOVE

Description

Fit 2 – 6.5 HP Small Engines Parts Honda GC160, GC190, GX120, GX140, GX160, GX200

Go Kart Minibike Belt Direct Drive Fun Kart Centrifugal Clutch 3 4 Bore 12 Tooth #35 Chain

Fit Briggs & Stratton 2 – 6.5 HP with 3/4″ Shaft 212 212cc Predator Engine Clutch

Fit Centrifical Tecumseh Engines 2 – 6.5 HP with 3/4″ Shaft and Any Other Go Cart Motor Auto Engines with 3/4 Crank Shaft and 3/16″ Key Way

3 4 inch Bar Centrifugal Clutch Performance Parts
Size:5/8″ Bore 12T
Picking the right toy is one of the most enduring dilemmas faced by parents and grandparents, by uncles and aunts, and by godfathers and godmothers. Kids love toys, but nowadays there?s too much emphasis on gaming consoles and handheld video games. As a gift-giver, your responsibility is to give them something fun that can get them outdoors. But it must not be dangerous for the kids.So the Mini bike Go kart Fun kart should be the best choice.
Specifications:
Outside diameter: 4 3/4″
Total width: 3″
Clutch back to sprocket: 2 1/2″
Fits:
2-6.5hp Honda & Honda Cloned Engines GC160, GC190, GX120, GX140, GX160, GX200
Briggs & Stratton Tecumseh Engines 2 – 6.5 HP With 3/4″ Shaft
Other engines with 3/4 crank shaft and 3/16″ key way
Oiling the clutch is extremely important, where do you oil the clutch
Oiling the clutch is extremely important. If heat damage occurs, the clutch will never disengage and the machine will start taking off by itself as soon as you start the engine. This is very dangerous! You can see heat damage inside the clutch drum, the metal turns from black to a blue color.
Where do you oil the clutch?
Behind the snap ring, next to the sprocket teeth at the end of the clutch. There’s an internal bronze bushing behind the snap ring that requires lubrication and it’s up to you to put it there each time.
It’s a good idea to oil the chain at the same time. If the chain gets kinky from lack of oil it should be replaced before it damages the clutch sprocket. A new chain is cheaper than a new clutch.
