This is a high class and durable live axle kit for DIY rebuild go kart quad, trikes or drift bikes

Fits 6 inch wheels (rim) with 3 bolt pattern and 3 inch bolt to bolt space

Overall length: 740mm (29 1/8 inch), the thickest part of the shaft is 22mm

For more size information, refer to the second image

Package includes: (1) Axle Assembly (1) T8F Sprocket (1) Brake D(2) Pillow Block
Ifyouarelookingfor35#chainsprocketforthisaxlekit,heretheASINnumber:B08H4NRBN3This is a high class and durable live axle kit for rebuild go kart quad or trikesPackage includes (just as main image): (1) Axle Assembly, (1) T8F Sprocket, (1) Brake Disc, (2) Pillow Block
Specs:Shaft Overall length (from end to end): 740mm (29 1/8″)The thickest part of the shaft is 22mm (7/8″)Chain Sprocket: T8F 58 TeethBrake Disc Diameter: 160mm(6 1/4″)Bearing model: 6904RS
If needed just contact seller for more detailed dimension and spec.The position of brake disc and sprocket can be changed, but the longer gold
