For all Doodle Bug versions
Manual choke
Fuel shut-off valve
Top-quality
97cc carburetor for Baja Blitz, Dirt Bug, Doodle Bug, and Racer mini bikes
This is the Baja factory replacement carburetor with a 3/4″ (19 mm) diameter intake 97cc carburetor for Baja Blitz, Dirt Bug, Doodle Bug, and Racer mini bikes. This is the Baja factory replacement carburetor with a 3/4″ (19 mm) diameter intake.

The Doodle Bug mini bike carb has a manual choke and fuel shut-off valve.

See Specifications for detailed dimensions. Engine Size(s): 97 cc
Air Intake Inner Diameter: 19 mm
Engine Intake Inner Diameter: 15 mm
Overall Depth: 5.1 cm
Overall Width: 9 cm
Overall Height: 10 cm
Choke: Manual
Mounting Hole Diameter: 6 mm
Mounting Hole Center to Center Distance: 41 mm
Drain: No
Fuel Shutoff: Yes
