Manual choke
19 mm intake
Fuel shut-off valve
Popular mini bike carb
The 97cc carburetor for the Motovox go-karts and the Motovox MBX10 and MBX11 mini bikes is also compatible with the Baja Doodle Bug
This replacement carburetor has a 3/4″ (19 mm) diameter intake The 97cc carburetor for the Motovox go-karts and the Motovox MBX10 and MBX11 mini bikes is also compatible with the Baja Doodle Bug. This replacement carburetor has a 3/4″ (19 mm) diameter intake.
Carburetor has a manual choke, fuel shut off valve, and is manufactured by Huayi and designed in Japan. Specifications

Engine Size(s): 97 cc
Air Intake Inner Diameter: 19 mm
Engine Intake Inner Diameter: 15 mm
Overall Depth: 5.1 cm
Overall Width: 9 cm
Overall Height: 10 cm
Choke: Manual
Mounting Holes Diameter: 10 mm
Drain: No
Fuel Shutoff: Yes
