DIYMINIBIKES

These are Titan Clutch Replacement Parts
Available Parts:
1. Snap Ring (01900004) (TDAP1902)
2. End Play Washer (02400116) (TDAP2404)
3. Bearing (14 -22T) (03000133) (TDAPSP3005)
4. Sprockets (click here)
5. Clutch Drum (01501463) (TDAPMCD)
6. Spiral Snap Ring (01900433) (TDAPSP1908)
7. Thrust Spacer (02400214) (TDAPSP2416)
8. Thrust Bearing (03000129) (TDAPSP3012)
9. Hub Shaft (01501463) (TDAPTP454)
10. Clutch Inside Dust Cover (02800446) (TDAPTP452)
11. Clutch Shoe (01200012) (TDAPTP10)
12. Clutch Hub (01430014) (TDAPTP1314)
13. Clutch Dust Cover Bolt (04000059) (TDAPSP2033)
14. Springs (click here)
15. Clutch Outside Dust Cover (02800445) (TDAPTP450)
16. Cartridge Spacer Washer (190079) (TDAP2405)
17. Clutch Assembly Snap Ring (1900079) (TDAPTP14)
18. Clutch Key (02500015) (400969
19. Mounting Bolt & Washer (TDAPTP34)
20. Crank stepped end washer (TDAP238)
21. Sprocket Shim (TDAP219)
22. Fiber Washer – hub/hub shaft (TDAP2468)
23. Fiber Washer – Outer (TDAP2066)
