Replacement parts for the Model 485 and 486
Parts List:
2 – 6. Tie Rod Assembly (KAZ877-6)
2 – 7. Tie Rod Assembly Long (KAZ8277-8)
14. 16 X 8 – 7.00 Knobby Tire (260027)
16. 145/70-6 Knobby Tire (260016)
17. High Speed Wheel Bearing with Snap Ring (5/8″ x 1-3/8″) (600630)
19. Inner Tube (Repair Part) (300215)
28. Sprocket #41 60T (5-1/4″ Bolt Circle) (AZ2166-60)
42. Gas Pedal (400751)
43. & 48. Brake & Throttle Pedal Springs (MAN9502-9503)
52 – 65. Brake Caliper (400281)
23. Brake Lining for Caliper (400289)
79. Bronze Bushing (200349)
88. 30 Series Torque Converter Drive Replacment Belt (203591)
107. 9T #41 TAV Replacement Sprocket (400847-9)
150. 30 Series Drive Pulley (453034)
151. 30 Series Driven Pulley (463586)
152. Three Point Seat Belt (501117)
