Description

This Chinese rear brake assembly is the replacement part for the Coleman KT196 and Hisun GK200 go-karts. The assembly has the brake master cylinder, caliper, brake line hose and brake fluid reservoir.
Master Cylinder description:
Mounting holes on master cylinder are 45mm [1.8″] center-to-center apart
Adjustable length piston with clevis and pin
Reservoir mounts on the top
Hose to reservoir is about 188mm [7.5″] long
Shipped with brake fluid in reservoir
Reservoir has metal reinforced mounting hole on side
Caliper details:
Mounting holes are 65mm [2.5″] center to center apart
Includes pads
Includes bleeder screw
Hose is approximately 5.5′ long. This is an OE assembly from Hisun.
