Description
Spindle and UPGRADED Ball Joint Assembly for Coleman KT196 and the HiSun HS200GK Go-Karts
As you know, the ball joints and spindles are prone to failure on these Coleman KT196 go-karts. This spindle has been installed with new upgraded ball joints at the factory. Please see pictures and measurements to determine if it will work for you. Original equipment ball joint was 22mm around with an 8mm stud; replacement ball joint is 26mm around with a 10mm*1.25 stud. Will require drilling out the holes in the upper and lower arms in order to retro-fit the new unit.
Product Specs:
Left [Driver] or Right [Passenger] Side
Includes ball joint
Round tube length: 154mm [6.07″]
Tube OD: 32mm [1.25″]
Tube ID: 26mm [1″]
Length of stud: 63.2mm [2.49″]
Stud is threaded M12*1.25 with cotter key hole
Arm at top is 80mm [3.14″] long
Arm has 8.6mm hole at the end
Nuts and Bolts not included
Fits all Coleman KT196 and the HiSun HS200GK go-karts
