REDUCTION GEARBOX APPLICATIONS:
NORAM??s reduction gearboxes were designed specifically for cement mixers, construction equipment, conveyors, roofing equipment, shrimp pot pullers, and cranberry harvesting equipment and a variety of other applications that require a 6:1 reduction.
FEATURES AND BENEFITS:
The GB6-7575 gearbox is a completely redesigned reduction unit that offers outstanding cost to functionality benefits. It is a bolt-on reduction gearbox with a 3/4 shaft featuring 6:1 gear reduction.
Now in stock and immediately available to satisfy your unique project demands.
Designed to fit most small (3/4 bore) 4-cycle engines.
Convenient bolt-on design adapts to most engine makes and models.
Rated up to 8 HP.
Provides flexibility in engine selection by eliminating the need to purchase costly special engines with lengthy delivery lead times.
Constructed of rugged, aluminum castings and precision machined gears for maximum longevity.
Features heat treated helical gears for quiet, optimum torque-carrying capacity.
Sports an industrial strength aluminum die cast housing.
Ball-bearing supported PTO shaft.
Reduction gearbox mounting kits available for various crankshaft configurations.
Specs:
Gear Reduction: 6:1
Horsepower: Up to 7 HP
Input Shaft: 3/4??
Output Shaft: 3/4??
Keyway: 3/16
