With a combination of this sprocket hub adapter plate and a standard wheel hub you have a sturdy, lightened, sprocket hub that can be easily allow a sprocket change.
Features:
Universal Aluminum Sprocket Hub Adaptor
Works with standard wheel hubs (4 on 2-13/16, 4 on 2-7/8, and 4 on 4)
Works with Spiderbox, allows for sprocket change from the 31T to larger sprockets.
Really useful for dual flange hub applications
Product Specs:
Outside Diameter: 5.9″
Center Bore: 2.3″
Quad Bolt Hole Pattern for multiple hubs (color in secondary photo):
(4) 5/16″ Holes on a 2-13/16″ Bolt Circle (green)
(4) 3/8″ Holes on a 2-7/8″ Bolt Circle (yellow)
(4) 1/2″ Holes on a 4″ Bolt Circle (red) –
Use with bolt spacers / extensions.
(4) 5/16″ Holes on a 3-1/8″ Bolt Circle (blue):
Spiderbox pattern
Sprocket Bolt Pattern: (6) 1/4″ Bolt Holes on a 5-1/4″ Bolt Hole Circle
Photos with sprockets and wheel hubs are just for reference, this listing is for the adapter plate only!
