Product Specs:
Fits ALL 8HP – 16HP engines with a 1″ straight crankshaft with 1/4″ keyway.
You will only find this very easy to install 40 Series Torque Converter Kit. Great upgrade for go-karts, buggys and more!
Comes with Driver Clutch, Driven Clutch, Belt, Jackshaft and all mounting hardware attached to an easy to mount backing plate.
Please look at picture in listing to see the mounting dimensions to be sure this will fit your engine. (Vertical holes 3 1/2″, Diagonally 5″)
For 8-16 hp engines. Same concept as the TAV2 kits used on the smaller engines.
If used on engines larger than 16hp, you will burn up belts.
Replaces 40 Series and Many Others
Replaces OEM Part Numbers: 203015 203015A
: 209133A, 209133, 209139A, 209139, 209151A, 209151
Manco: 2432
Kit Includes:
1- 40 series driver for 1″ crankshaft
1- 40 3/4″ series driven pulley
1- 40 series 7/8″ wide drive belt
1- 10T Sprocket for 40/41/420 chain
1- Jackshaft assembly
1- Heavy duty (cast or stamped steel) back plate with all mounting hardware
Outer cover with mounting hardware
Installation Notes:
Drive Unit; Must be installed Inboard on the crankshaft!
