Band Brakes & Brake Drums
Band Brakes are simple, effective and economical for a
variety of light duty vehicles. Two popular sizes for 4″ or
4-1/2″ drums and also a 3-3/4″ size. Brake Pin included.
3 Sizes
Steel Bands
Steel Brake Pin with Cable Hole
Economical

DESCRIPTION – 4-1/2″
PART NO.
Band Brake for 4-1/2″ Drum + Pin, Skin-Packed
2255
Band Brake for 4-1/2″ Drum + Pin, Bulk
2255-B
Brake Pin (Replacement)
2254

DESCRIPTION – 4″
PART NO.
Band Brake for 4″ Drum + Pin, Skin-Packed
2251
Band Brake for 4″ Drum + Pin, Bulk
2251-B
Brake Pin, (Replacement)
2254

DESCRIPTION – 3-3/4″
PART NO.
Band Brake for 3-3/4″ Drum + Pin, Skin-Packed
2252
Band Brake for 3-3/4″ Drum + Pin, Bulk
2252-B
Brake Pin (Replacement)
2254
4-1/2″ BRAKE DRUMS, MACHINED
Machined OD for Band Brake Use
2-1/8″ Center Bore
Zinc-Plated
Flanged drum has 6 holes on a 5-1/4″ bolt circle. Machined “OD” for band brakes.
All drums have 3 sets of moutning holes: 3 & 4 hole on a 3.75″ diameter bolt circle
and a 4 hole on a 3.228″ bolt circle to match the Mini-Hub.
DESCRIPTION
PART NO.
Drum, 4-1/2″, Machined OD, No Flange
2211-OD
Drum, 4-1/2″, Machined OD, With Flange
2213-OD
4″ BRAKE DRUM
For use with 4″ Band Brake
2.875″ Bolt Circle
4 Holes – 5/16″ & 3/8″
2″ Center Bore
Zinc-Plated
DESCRIPTION
PART NO.
Brake Drum, 4″ – No Flange
2541
4-1/2″ BRAKE DRUMS WITH RIVETED HUBS
Mini-Hubs (3/4″, 1″ or 1-1/4″ bore), riveted to any of our 4-1/2″ drums
for use on a 3/4″, 1″ or 1-1/4″ Live Axle. Ideal for small, low horsepower
vehicles. Set Screws and Key included. Drums and Mini-Hubs are Zinc-Plated.
DESCRIPTION (MACHINED OD)
PART NO.
72 Tooth Sprocket – #35 Chain, Drum & 3/4″ Hub Kit
2468-OD
72 Tooth Sprocket – #35 Chain, Drum & 1″ Hub Kit
2268-OD
72 Tooth Sprocket – #35 Chain, Drum & 1-1/4″ Hub Kit
2248-OD
60 Tooth Sprocket – #35 Chain, Drum & 3/4″ Hub Kit
2467-OD
60 Tooth Sprocket – #35 Chain, Drum & 1″ Hub Kit
2267-OD
60 Tooth Sprocket – #35 Chain, Drum & 1-1/4″ Hub Kit
2247-OD
Flanged Drum & 3/4″ Hub Kit
2466-OD
Flanged Drum & 1″ Hub Kit
2266-OD
Flanged Drum & 1-1/4″ Hub Kit
2246-OD
Drum, No Flange & 3/4″ Hub Kit
2465-OD
Drum, No Flange & 1″ Hub Kit
2265-OD
Drum, No Flange & 1-1/4″ Hub Kit
2245-OD
SINGLE-PIECE, 4-1/2″ SPROCKET DRUMS, ZINC-PLATED
Stamped for added precision, our one-piece #35 chain, 60 or 72 tooth Steel
Sprocket and 4-1/2″ Drum combinations provide strong, reliable units at
economical prices. (Replaces riveted assemblies.)
DESCRIPTION
PART NO.
Drum, Machined OD &
60 tooth Sprocket, Plated
2217-OD
Drum, Machined OD &
72 tooth Sprocket, Plated
2218-OD
4″ BRAKE DRUM WITH MINI-HUB
Our Mini-Hub, 3/4″ or 1″ bore plus 4″ Brake Drum, with Hardware Kit
for use on 1″ Live Axle. Ideal for small, low horsepower vehicles.
Drums and Mini-Hubs are Zinc-Plated.
DESCRIPTION
PART NO.
Mini-Hub, 3/4″ Bore with 4″ Brake Drum
plus Hardware Kit
2461
Components
4″ Brake Drum, Zinc-Plated, No Flange
2541
Mini-Hub, Zinc-Plated, 3/4″ Bore, 3/16″ Keyway &
Set Screws, P5263 Bolt Pattern
2568
Hardware Kit
2563-3/4
Components
Mini-Hub, 1″ Bore with 4″ Brake Drum
plus Hardware Kit
2460
4″ Brake Drum, Zinc-Plated, No Flange
2541
Mini-Hub, Zinc-Plated, 1″ Bore, 1/4″ Keyway &
Set Screws, P5263 Bolt Pattern
2561
Hardware Kit
2563
