The Coyote XP Kart is the perfect chassis for Sprint kart racing.
Features:
Adjustable Castor and Camber: Lets driver increase or decrease the castor angle 8o from center, or adjust camber 2o up or down on either side. These are two independent adjustments. No need to align front end after adjusting.
Seat available in Sprint or Laydown (all sizes)
Supernerfs
Rear Axle : 1-1/4″ or 40mm tubular chromoly axle with snap ring.
Low friction free-spinning rear end bearings
Douglas one-piece wheels
Oven bake polyurethane paint.
Product Specifications:
Wheel Base: 41
Overall Length: 67
Overall Height: 18
Dry Weight: 100lbs
Tread Width Adjustable: Front: 37-1/4 – 44 Rear: 40 – 55
Kingpin Centerline: 25-1/4
Bolt-on chrome plated front and rear bumpers
Axle cassettes, long-bolt spindles, and steering shaft locking block: Standard
Steering Components
Aluminum tie rods with right and left threads 3/8 aircraft grade tie rod ends. Steering column is adjustable. Fasteners are safety wired. King pin angle 10 degrees.
