Inferno BLAZE Tunable Racing Clutch, 3/4″ bore (no sprocket included)

Does not come with sprocket, needs to be ordered seperately
Shoes in breakdown are for reference and do not look like the shoes included with this clutch.
Fits 3/4″ shafts
Built in 3/16″ key
Heat Treated Hub
Machined Drum
2 piece design
Easy changes without chain removal
Unlimited Track Tunability
Quick change spring sets mean less time in the pits and more time on the track
Upgraded needle bearing and race to replace short bushing.
Interchangeable Sprockets
Thermo-Dynamically Designed
Tunability at a competitive price
Longer Life
Different size weights offer infinite tuning possibilities: different engagement RPM’s and alters torque capacity.
Shoe Configuration
Leading Shoe – Maximum torque (less slip)
Combination – Average torque (average slip)
Trailing Shoe – Less torque (more slip)
Kit includes reference #1, #2, #3, #4, #5 orange (4), #5 yellow (4), and #5 white (4), 4 Heavy Weights, 4 Light Weights, 24 Weight Snap Rings, #6, #7, #8, #9, #10, #12, #13, #14, #15.
Blaze
Reference #
OEM Part #
MFG Supply Part #
Description
1
8444-22-016
HSPACER
1/4″ Thick Crankshaft Spacer
2
8444-9U-019
Part included in HBLAZE
Hub Spacer
3
8444-12-003
Part included in HBLAZE
Guard
3
8444-23-089
Part included in HBLAZE
3/4″ Heat Treated Hub
4
8444-31-009
Part included in HBLAZE
Tunable Racing Shoe
5
8443-35-002-A
HIRED
Red Spring (1200 RPM)
5 – Included
8443-35-003-A
HIORANGE
Orange Spring (1800 RPM)
5 – Included
8443-35-004-A
HIYELLOW
Yellow Spring (2000 RPM)
5 – Included
8443-35-005-A
HIWHITE
White Spring (2300 RPM)
5
8443-35-006-A
HIBLACK
Black Spring (3000 RPM)
5
8443-35-009-A
HIGREEN
Green Spring (830 RPM)
Not Shown in
Breakdown
8444-22-005
HIWHEAVY
Heavy Weight
Not Shown in
Breakdown
8444-22-006
HIWLIGHT
Light Weight
Not Shown in
Breakdown
1279-01-033-T
HIWSR
Weight Snap Ring
6
8444-21-007
Part included in HBLAZE
Washer with Internal Key
7
8444-12-011
Part included in HBLAZE
Grease Trap
8
8444-22-009
Part included in HBLAZE
Hub Spacer
9
1279-01-136-T
HISR
Bowed Snap Ring
10
8444-13-099
Part included in HBLAZE
Racing Housing
11
8444-47-117
HI1135-B
11 Tooth #35 Chain Sprocket – Bearing
11
8444-47-045
HI1235-B
12 Tooth #35 Chain Sprocket – Bearing
11
8444-47-093
HI1335-B
13 Tooth #35 Chain Sprocket – Bearing
11
8444-47-094
HI1435-B
14 Tooth #35 Chain Sprocket – Bearing
11
8444-47-095
HI1535-B
15 Tooth #35 Chain Sprocket – Bearing
11
8444-47-096
HI1635-B
16 Tooth #35 Chain Sprocket – Bearing
11
8444-47-097
HI1735-B
17 Tooth #35 Chain Sprocket – Bearing
11
8444-47-098
HI1835-B
18 Tooth #35 Chain Sprocket – Bearing
11
8444-47-099
HI1935-B
19 Tooth #35 Chain Sprocket – Bearing
12
8444-9U-034
HIBEARING
Needle Bearing and Race Assembly
13
8444-22-015
Part included in HBLAZE
Washer
14
0414-00-077-T
Part included in HBLAZE
Lock Washer
15
0400-05-034-T
Part included in HBLAZE
Bolt
