Inferno Fire Racing Clutch. 3/4″ bore (no sprocket included)

Does not come with sprocket or optional weights, needs to be ordered seperately
The Inferno Fire racing clutch is the latest engineered product for the racing industry. The Fire clutch includes all of the design advantages of the Flame with several new features that make the Fire the best drum clutch available on the market. The Fire clutch has a bonded friction lining that improves consistency and performance. The friction material has been engineered to have a dynamic coefficient of friction that is very close to the static coefficient of friction. This creates a flatter engagement profile with less engine bogging during lock-up. The racer can utilize the optional weights to fine tune the clutch to keep the rpm in a band close to peak engine torque. This is very important for sprint racing to get the best acceleration off the corners. The Fire clutch is ideal for the LO206 engine because of the smooth engagement and the ability to tune the clutch for each color slide. The friction lining prevents the drum surface from galling so no sanding is needed inside the drum and the clutch should be cleaned with brake cleaner. Other new features include the needle bearing design, grease trap and drum vents. The grease trap is engineered to catch any grease or oil that comes out of the bearing. The added radial vents allow any debris to quickly exit the clutch without getting trapped under the shoes. Less contamination in the clutch gives better consistency and performance. These new features make the Fire clutch the best choice for all classes. It is recommended to add the optional weights in classes weighing 400# or over for additional torque capacity.
Fits 3/4″ shafts, Built in 3/16″ key.
Kit includes reference #1, #2, #3, #4, #5 black (4), #5 white (4), #6, #7, #8, #9, #10, #12, #13, #14, and #15.
Reference #
OEM Part #
MFG Supply Part #
Description
1
8444-22-016
HSPACER
1/4″ Thick Crankshaft Spacer
2
8444-9U-019
Part included in HFIRE
Hub Spacer
3
8444-12-003
Part included in HFIRE
Guard
3
8444-23-089
Part included in HFIRE
3/4″ Heat Treated Hub
Not Shown in
Breakdown
8444-22-006
HIWLIGHT
Light Weight
Not Shown in
Breakdown
8444-22-005
HIWHEAVY
Heavy Weight
4
8444-31-019
Part included in HFIRE
Tunable Fire Racing Shoe
Not Shown in
Breakdown
1279-01-033-T
HIWSR
Weight Snap Ring
5
8443-35-009-A
HIGREEN
Green Spring (830 RPM)
5
8443-35-002-A
HIRED
Red Spring (1200 RPM)
5
8443-35-003-A
HIORANGE
Orange Spring (1800 RPM)
5
8443-35-004-A
HIYELLOW
Yellow Spring (2000 RPM)
5 -Included
8443-35-005-A
HIWHITE
White Spring (2300 RPM)
5 – Included
8443-35-006-A
HIBLACK
Black Spring (3000 RPM)
6
8444-21-007
Part included in HFIRE
Washer with Internal Key
7
8444-12-011
Part included in HFIRE
Grease Trap
8
8444-22-009
Part included in HFIRE
Hub Spacer
9
1279-01-136-T
HISR
Bowed Snap Ring
10
8444-13-198
Part included in HFIRE
Fire Racing Drum
11
8444-47-117
HI1135-B
11 Tooth #35 Chain Sprocket – Bearing
11
8444-47-045
HI1235-B
12 Tooth #35 Chain Sprocket – Bearing
11
8444-47-093
HI1335-B
13 Tooth #35 Chain Sprocket – Bearing
11
8444-47-094
HI1435-B
14 Tooth #35 Chain Sprocket – Bearing
11
