Does not come with sprocket or optional weights, needs to be ordered seperately
The Flame clutch includes all of the design advantages of the Fury but also includes several additional features. The clutch is fully tunable with optional weights. The optional weights alow the racer to make small adjustments to the engaging speed for optimal performance. The shoes have been designed to reduce chatter and provide smoother engagement over the Fury clutch. The shoes are lighter than a Fury shoe which reduces the inertia and include cleaning grooves to collect dirt/debris. The cleaning grooves maintain a smooth drum surface with less galling. The quick change springs, tuning weights, and new shoe design (with increased surface area) make the Flame clutch a great choice for the clone or LO206 for weight classes 400# or less. It is recommended to add the optional weights for super heavy classes.
Fits 3/4″ shafts, Built in 3/16″ key.
HIBEARING
will be required for bearing type sprockets.
Kit includes reference #1, #2, #3, #4, #5 black (4), #5 white (4), #6, #7, #8, #9, #10, #12, #13, #14, and #15.
Reference #
OEM Part #
MFG Supply Part #
Description
1
8444-22-016
HSPACER
1/4″ Thick Crankshaft Spacer
2
8444-9U-019
Part included in HFLAME
Hub Spacer
3
8444-12-003
Part included in HFLAME
Guard
3
8444-23-089
Part included in HFLAME
3/4″ Heat Treated Hub
Not Shown in
Breakdown
8444-22-006
HIWLIGHT
Light Weight
Not Shown in
Breakdown
8444-22-005
HIWHEAVY
Heavy Weight
4
8444-31-017
Part included in HFLAME
Tunable Flame Racing Shoe
Not Shown in
Breakdown
1279-01-033-T
HIWSR
Weight Snap Ring
5
8443-35-009-A
HIGREEN
Green Spring (830 RPM)
5
8443-35-002-A
HIRED
Red Spring (1200 RPM)
5
8443-35-003-A
HIORANGE
Orange Spring (1800 RPM)
5
8443-35-004-A
HIYELLOW
Yellow Spring (2000 RPM)
5 -Included
8443-35-005-A
HIWHITE
White Spring (2300 RPM)
5 – Included
8443-35-006-A
HIBLACK
Black Spring (3000 RPM)
6
8444-21-007
Part included in HFLAME
Washer with Internal Key
7
8444-12-011
Part included in HFLAME
Grease Trap
8
8444-22-009
Part included in HFLAME
Hub Spacer
9
1279-01-136-T
HISR
Bowed Snap Ring
10
8444-13-099
Part included in HFLAME
Flame Racing Drum
11
8444-47-117
HI1135-B
11 Tooth #35 Chain Sprocket – Bearing
11
8444-47-045
HI1235-B
12 Tooth #35 Chain Sprocket – Bearing
11
8444-47-093
HI1335-B
13 Tooth #35 Chain Sprocket – Bearing
11
8444-47-094
HI1435-B
14 Tooth #35 Chain Sprocket – Bearing
11
8444-47-095
HI1535-B
15 Tooth #35 Chain Sprocket – Bearing
