Universal Suspension Kit for Mega, some Coleman and many others
Part number: SUSPENSIONKIT Product Description
rubber seals ensure a long life of this telescopic front end. With its fully adjustable lower fork clamp, this front end can be mounted onto virtually any mini bike with a similar length set of forks. If your mini bike has a 5/8″ kingpin or axle then simply enlarge the kingpin/axle holes with a 5/8″ drill bit. Direct Bolt On Applications Monster/ Mega Moto 80cc / 105cc Motovox 80cc / 105cc All Doodlebugs/Small Bajas (originally equipped with a 4hp or smaller engine) This hydraulic front end can be modified to fit virtually any old school mini bike with similar length forks. Will not fit Coleman 200 series bikes. Included with this kit: Two telescoping forks Upper fork plate with bolts Lower fork clamp with pinch bolts 12mm axle bolt 12mm axle nut Axle spacers Dimension: Length (top plate to center of axle) – 19″ Inner fork clearance (distance between the two forks) – 6.875″ Forks hold 3 oz. of FORK OIL.
