Mounts turn signals/Mirrors BAR End Motogadget Bars 7/8′ E 1 “

The uni disc / cone handlebar adapter allows the mounting of all mo.view bar-end mirrors in combination with the mo.blaze turn signals without moving the handlebar grips and controls. Creates a locking surface for the handlebar end mirror on the outside of the head tube and at the same time allows the mounting of the handlebar end indicators. Whether it is mo.view blade, mo.view spy, mo.view flight, mo.view cafe , mo.view road, mo.view pace, mo.view cruise or mo.view STREET .
It is CNC machined from billet aluminum and black anodized. Locking at the end of the handlebar is done by tightening an M6 screw inside the adapter, whereby the locking pieces are widened and a stable assembly becomes possible. Then the mirror clamp on the adapter is tightened and the handlebar end indicator is locked at the same time.
The uni disc / cone handlebar adapter comes with two clamps for the left and right side of the handlebar. They fit perfectly with our mo.grip knobs and mo.switch basic and mo.switch mini buttons.
They are mounted directly to the handlebar end (22mm, 7/8 and 1 inch) with an internal diameter (unthreaded) of 12 to 21mm and a length of 90mm.
For all 22mm, 7/8 and 1 inch handlebars with a free internal diameter of 12 to 21mm
Total length: approx. 105 mm, a free inner tube length of at least 90 mm is required
Mirror mounting surface width: 8mm, compatible with all handlebar end mo.view mirrors
Clamping surface diameter: 1 inch, fits all mo.view handlebar mirrors
Sold in packs of n. 2 pieces right + left
