Product Description
Genuine TAV2 Torque Converter. Part number 218352A.
3/4″ bore
12 Tooth
#35 Chain
3/16″ Keyway
Made by Comet. Made in USA The Torq-A-Verter is a fully automatic variable speed drive system (torque converter). There are no gears, no complicated controls or levers and neither manual shifting nor clutching is involved in these systems. The unique design of the movable face in each driver and driven member causes automatic infinite variation and thus smooth shifting action between the system’s low and high range in immediate response to changing load and/or travel conditions..with constant optium ratio between engine and drive wheels ensuring that you get the use of all the power your engine develops. Since ratio selection and “down-shifting” is automatic, braking and vehicle control are enhanced. The Torq-A-Verter system engages at 2200 rpm. As the engine throttle is “opened” the drive belt engages, driving the driven unit at it’s largest diameter. This is the most powerful ratio of the system (2.7:1). At the highest speed (overdrive) and lowest load demand the driven unit pulley flanges are wide open providing the smallest possible belt contact diameter. The drive unit pulley flanges are closed to provide the largest possible belt contact diameter. This gives the system an overdrive ratio of .90:1. TAV2 – Torque Converter – 3/4″ 12T #35 Chain 3/16″ Keyway
